RT-630 disk chopper is designed for shredding branches, trunks with a diameter of up to 13 cm, and other wooden materials e.g. lumber-mill chips. The thickness of forest chips may be adjusted by means of four replaceable blades (made of HRDOX 500 steel), by adjusting their position against counter-blade. Blades are fixed to cutting disk with a diameter of 630 mm, which due to its weight serves as a flywheel.
The chopper is fitted with protective covers providing safe operation. Discharge stack may be rotated 360˚ in order to discharge stream of chips in proper direction. The chopper is characterised by high capacity and high comfort of operation. Chips may be used as a fuel (useful for screw feeders) or as a compost or a priming for shrubs.
Chopper’s drive is transmitted by power transmission shaft from tractor’s WOM (right-hand rotation). We recommend using power transmission shafts fitted with a shear pin coupling (available in our offer), in the case of machine overload the pin is sheared thus switching off the drive. Lubricating of rolling bearing is done by means of grease nipples in bearing shell.
15 / 45 km
Number of cutters on the cutting disk
4 +1 counter-edge / counter
Recommended PTO drive speed
Direction of rotation of the WOM roller
Max. cutting diameter of branches
dry hard wood 70 mm
fresh hard wood 100 mm
fresh soft wood 120 mm
Size of chips
Cutting disk diameter
Manufacturing of cutters
HARDOX steel type 500
Thickness of cutters
Angle of rotation of the outlet pipe
Chipper attachment system
Three-point suspension system
Trailer attachment: towing power
Height of the ejection tube
Dimensions of the chipper with folded hopper long (LxWxH)
